🔧 Introduction:
Mobile IC Tester and Tracing Tools – Complete Guide in Urdu
Mobile repairing mein IC testers aur tracing tools ka use technician ke liye game changer hota hai. Yeh tools not only time save karte hain, balki short fault aur damaged ICs ko accurately detect karne mein madad karte hain. Is guide mein aapko mile
✅ Mobile IC Tester ka istemal kaise karein
✅ Tracing tools se fault kaisay trace hota hai
✅ Best brands aur budget tools
✅ Urdu mein simplified explanation
📟 1. Mobile IC Tester Kya Hota Hai?
IC Tester ek electronic device hai jo mobile board pe lagay different ICs — jaise charging IC, power IC, audio IC — ki functionality aur fault detection karta hai.
✅ Use Cases:
IC short hai ya ok?
Duplicate IC detect karna
IC ka voltage level sahi hai ya nahi
Real-time test with socket support
💡 Pro Tip: Tester use karne se board ko unnecessary heat dene se bacha ja sakta hai.
⚙️ 2. Kaun Kaunse ICs Test Ho Sakte Hain?
Zyada tar testers following ICs test kar lete hain:
Charging IC
Power IC
Audio IC
Network IC
U2 IC (iPhones mein common)
Touch IC
Display IC
📌 Popular IC Testers:
Z3X Easy Jtag Plus
QianLi iPower Max
Wuxinji IC Tester
JC Programmer + IC module boards
📈 3. IC Tester Ka Use Kaise Karein – Step by Step
- 🔌 Power ON the tester device
- 📤 IC ko remove karein aur tester socket mein lagayein
- 📊 Display pe result dekhein: Pass / Fail
- 🔍 Voltage ya resistance reading agar abnormal ho to IC faulty ho sakta hai
- 📦 Replace IC if needed
💡 Safety Tip: Tester se pehle IC ko dry aur clean kar lein (IPA se)
🔦 4. Tracing Tools Ka Use – Fault Trace Karne Ka Asaan Tareeqa
Tracing tools se PCB board par fault ya shorted component trace kiya jata hai:
Types of Tracing Tools:
🔥 Thermal Camera / Infrared Camera (hotspot detect karta hai)
📟 Multimeter in continuity mode
🧲 Magnetic Short Finder
🧪 Logic Analyzer (advanced level)
✅ Use Cases:
Short component trace karna
No power ya auto restart issue diagnose karna
Charging ya display line ka voltage trace karna
📌 Pro Tip: Board diagram ya ZXW Tool + tracing tool = 100% fault detection success
🔍 5. Best Practices
Always disconnect battery pehle
Use magnifying glass / microscope for close tracing
Never overheat the board during testing
Document each test step for repeat cases
🔧 6. Price & Budget (PKR Estimates)
Tool Approx Price (PKR)
Basic IC Tester 6,000 – 10,000
Branded IC Tester 15,000 – 30,000
Thermal Camera 12,000 – 25,000
Magnetic Short Finder 1,500 – 3,000
✅ Conclusion:
Agar aap professional technician banna chahte hain, to IC testers aur tracing tools aapke repairing ka backbone ban sakte hain. Accurate testing = Happy customers = High income. Tools mein invest karna, time aur credibility dono ka faida hai.
